Introduction

Imagine having a web portal to showcase, document, test, and improve all your React Native components. A place where you can build your own library over time and then use that library to quickly build and release all those app ideas you have.

If that sounds appealing to you, you'll love Storybook.

In this post, I'll talk about what Storybook is, how it can help you, and how to add it to your Expo project, taking advantage of Expo SDK 49 new features and Expo Router v2.

At the end of the post, you’ll have a working repo with Expo SDK 49, Storybook for React Native, Expo Router v2, TypeScript, and more!

Show me the code

If you already know Storybook, and you just want a working repo to fork, here is the link to the Github repo

What is Storybook, and how can it help you?

Storybook is an open-source tool for building UI components and pages in isolation. In other words, it's a library you can add to your project to test and document your components.

Are you still confused? No worries. I had to read the official documentation and search for real-life examples before genuinely understanding how powerful this tool is. So, follow me with this basic example.

Let's say we have a simple "Button" component. It receives the following props:

text (string)
disabled (boolean)
onPress (function)

If you are working for a company, chances are that you'll have to communicate how your new component works to the rest of the team.

Besides, your teammates must know that your Button component exists to avoid code duplication.

Last but not least, you will need to test your component with different props combinations to make sure everything works as expected. For example, what happens if we use a really long text for our button? Is our component responsive?

Storybook is the solution to all the problems I mentioned before. It helps you build a centralized component library with rich and interactive documentation so your teammates can reuse or even improve it.

Setup options

There are two main ways to use Storybook with Expo. Based on what you choose, the installation process will be different.

Storybook web

You work on your React Native components as usual and reference those components as Stories that can be rendered directly into the browser.
You setup your Storybook project using the react starter
Then, you use Webpack to transpile your native modules into something you can run on your browser
Pros
- You can publish your Storybook web portal and share it with your teammates. Everyone can access the documentation and play with the components without having to install anything.
Cons
- Any native component like a Date time picker won't be rendered. For those components, you will need to use the other method described below.
- Even if you test your UI in the browser, some issues will only appear while running on a native device, so it’s not completely reliable.

Storybook native

You replace the entry point of your React Native app with the Storybook UI. Everything is presented directly within your native device.
You setup your Storybook project using the react-native starter
Then, you tweak metro bundler to handle the Storybook UI, which is rendered on a native device.
Pros
- You don't have any limitations to render native components like Date Time Picker because everything runs on your phone.
- The tests are completely reliable because you are running your components on a native device
Cons
- Reading documentation directly from your phone is not the best option if you want to promote collaboration within your team. Having a web interface is always better for developers who will spend hours a day working with a design system.

This article will be focused on showing how to run Storybook on a native device, but let me know if you are interested in learning how to build and deploy a web interface to share with the rest of the team. Maybe I could write about it in the next post.

Setting up an Expo project with Expo Router v2 and SDK 49

As of the writing of this article (July, 2023), I couldn’t find an official expo template that comes with TypeScript and Expo Router v2 configured, so let’s start by using the vanilla JS Expo Router starter and add TypeScript later.

Run the following command to create an empty project with Expo Router configured.
```
 npx create-expo-app@latest -e with-router
```
Because this starter comes with Expo SDK 48, we’ll need to run the following command to update Expo to SDK 49
```
 expo upgrade
```
Make sure to check if the starter already comes with SDK 49. Maybe it’s not necessary to do the upgrade anymore (The Expo team moves really fast)

You may need to install the expo-cli globally before running the upgrade. If that’s the case, run npm i -g expo-cli

Based on Expo official docs, for Expo Router v2 is no longer necessary to include the resolutions and overrides sections in the package.json, so we can delete them like this:

{
 "scripts": {
   "start": "expo start",
   "android": "expo start --android",
   "ios": "expo start --ios",
   "web": "expo start --web"
 },
 "dependencies": {
   ...
 },
 "devDependencies": {
   "@babel/core": "^7.20.0",
   "@babel/plugin-proposal-export-namespace-from": "^7.18.9"
 },
-"resolutions": {
-  "metro": "^0.73.7",
-  "metro-resolver": "^0.73.7"
-},
-"overrides": {
-  "metro": "^0.73.7",
-  "metro-resolver": "^0.73.7"
-},
 "name": "expo-router-storybook-starter",
 "version": "1.0.0",
 "private": true
}

Run the following commands to create an empty src folder where our components will be added, and an app folder for our application routes.
```
 mkdir src
 mkdir app
```

Adding TypeScript

Create an empty tsconfig.json by running this command
```
 touch tsconfig.json
```
With the tsconfig.json created, you can run npx expo start. Expo will detect a tsconfig.json file, ask you to install the missing dependencies, and handle the required setup for you, inheriting a few defaults from Expo’s base config.
Update the package.json to move both typescript and @types/react dependencies under devDependencies.

Adding support for Path Aliases (Optional)

Expo SDK 49 introduces support for Path Aliases. You can optionally follow these steps to setup a path alias for the src directory

Update your app.json by adding the “experiments” section like this:

{
 "expo": {
   "scheme": "acme",
   "web": {
     "bundler": "metro"
   },
   "name": "expo-router-storybook-starter",
   "slug": "expo-router-storybook-starter",
+  "experiments": {
+    "tsconfigPaths": true
+  }
 }
}

Update the tsconfig.json to apply this configuration to our src directory.

{
 "compilerOptions": {
+  "baseUrl": ".",
+  "paths": {
+    "@/*": ["src/*"]
+  }
 },
 "extends": "expo/tsconfig.base"
}

That’s it! Now you can import your components like this:

import Button from '@/components/Button';

Instead of doing this:

import Button from '../../components/Button'

Adding Storybook to the project

Thanks to the amazing Storybook CLI, adding Storybook to your project is as simple as executing the following command

npx storybook@latest init

A few things I would like to mention about this process:

Storybook will detect your framework and add all the required dependencies to your project
It will also add a few essential add-ons like:
- @storybook/addon-actions
  - Can be used to display data received by event handlers in Storybook.
- @storybook/addon-controls
  - Gives you a graphical UI to interact with a component's arguments dynamically, without needing to code. It creates an addon panel next to your component examples ("stories"), so you can edit them live.
- @storybook/addon-ondevice-actions
  - Allows you to log events/actions inside stories in Storybook while running on a mobile device
- @storybook/addon-ondevice-controls
  - Allows editing a component's arguments dynamically via a graphical UI without needing to code while running on a mobile device
You’ll see a new folder called .storybook that will include all the initial configs so you can run Storybook with the essential add-ons activated.
- Here you’ll also find a Button component with their stories. We’ll talk more about this component later

Opting out from package version validations for Storybook dependencies

During setup, Storybook will install a few additional dependencies that, at the time of this writing, will throw a warning when you run npx expo start due to a mismatch between the installed versions and the ones expected by Expo. I’m talking about @react-native-async-storage/async-storage and @react-native-community/datetimepicker

Because I want to keep these versions, I decided to take advantage of a new feature released with SDK 49, which allows you to opt out from package version validations for a list of dependencies.

Feel free to run expo doctor --fix if you want to downgrade your dependencies to the version expected by Expo.

To use this new feature, we need to update the package.json, adding an array with the dependencies we want to exclude from the validation.

{
  "scripts": {
    "start": "expo start",
    "android": "expo start --android",
    "ios": "expo start --ios",
    "web": "expo start --web",
    "storybook-generate": "sb-rn-get-stories",
    "storybook-watch": "sb-rn-watcher"
  },
  "dependencies": {
    ...
  },
  "devDependencies": {
    ...
  },
+ "expo": {
+   "install": {
+     "exclude": [
+       "@react-native-async-storage/async-storage",
+       "@react-native-community/datetimepicker"
+     ]
+   }
+ },
  "name": "expo-router-storybook-starter",
  "version": "1.0.0",
  "private": true
}

You can now run npm start and verify you no longer see the previous warnings

Using client environment variables to conditionally load Storybook UI

I wanted to use an environment variable to enable/disable the Storybook UI based on my needs during development, so I decided to try another new feature included in SDK 49: Client environment variables.

If you want to learn more about Environment variables in Expo, checkout the amazing official docs by the Expo team. They even included steps to migrate from different tools like direnv or react-native-config 🙌

When you use client environment variables, you can simply create an .env file, and add your keys using the EXPO_PUBLIC_ prefix, and Expo will automatically expose those keys through Metro. That means we no longer need the transform-inline-environment-variables babel plugin.

Remove the mentioned plugin from babel.config.js

module.exports = function (api) {
 api.cache(true);
 return {
   presets: ["babel-preset-expo"],
   plugins: [
-    "transform-inline-environment-variables",
     "react-native-reanimated/plugin",
     require.resolve("expo-router/babel"),
   ],
 };
};

Create an empty .env file
```
 touch .env
```
Update the new .env file, adding the following environment variable
```
 EXPO_PUBLIC_STORYBOOK_ENABLED=true
```

Because we are using Expo Router, we need to create a layout route. On this route, we’ll simply export a React component with a Slot, so Expo Router can render the child route there.

 touch app/_layout.tsx

 // app/_layout.tsx

 import { Slot } from "expo-router";

 let RootApp = () => {
   return <Slot />;
 };

 export default RootApp;

Then, add a new Index.tsx file inside the app directory. In this file, we’ll check the value of the environment variable to decide what to render

 touch app/Index.tsx

 // app/Index.tsx
 import React from "react";
 import { Text, View } from "react-native";
 import { SafeAreaView } from "react-native-safe-area-context";

 const storybookEnabled = process.env.EXPO_PUBLIC_STORYBOOK_ENABLED === "true";

 const Index = () => {
   return (
     <SafeAreaView>
       <Text>Hello world</Text>
     </SafeAreaView>
   );
 };

 let EntryPoint = Index;

 if (storybookEnabled) {
   const StorybookUI = require("../.storybook").default;
   EntryPoint = () => {
     return (
       <View style={{ flex: 1 }}>
         <StorybookUI />
       </View>
     );
   };
 }

 export default EntryPoint;

Updating metro config

Based on Storybook docs, we also need to customize our metro.config.js to use the sbmodern resolver field in order to resolve the modern version of storybook packages. Doing this removes the polyfills that ship in commonjs modules and fixes multiple long-standing issues such as the promises never resolving bug and more (caused by corejs promises polyfill).

Create a new metro.config.js file
```
 touch metro.config.js
```

Use the following configuration

 const { getDefaultConfig } = require("expo/metro-config");

 module.exports = (async () => {
   let defaultConfig = await getDefaultConfig(__dirname);
   defaultConfig.resolver.resolverMainFields.unshift("sbmodern");
   return defaultConfig;
 })();

Loading Storybook with `npm start`

We’ll need to update our start script so Storybook can load the stories before the app starts.

{
  "scripts": {
-   "start": "expo start",
+   "start": "sb-rn-get-stories && expo start",
    "android": "expo start --android",
    "ios": "expo start --ios",
    "web": "expo start --web",
    "storybook-generate": "sb-rn-get-stories",
    "storybook-watch": "sb-rn-watcher"
  },
  ...
}

With everything in place, we should be able to run our app and see the Storybook UI like this:

Storybook UI in React Native

If you now go to your .env file and set EXPO_PUBLIC_STORYBOOK_ENABLED to false, you can hit reload on your running app, and instantly see how your app loads instead of the Storybook UI 🪄

After running your app for the first time with Storybook, you should see a new file that was automatically generated by Storybook. I’m talking about the storybook.requires.js file. Please avoid changing this file.

We could stop here, but I wanted to add a few stories using TypeScript, so everything is set up correctly. Let’s work on that!

Cleaning up

One thing I don’t like about the default Storybook setup, is that it adds two example files: .storybook/stories/Button.js and .storybook/stories/Button.stories.js. If you are new to React Native and to Storybook, you may think it’s a good idea to store all your components directly in the .storybook/stories directory. Instead, I want to create a Button.tsx component inside src/components, and then import that component into my Storybook story.

Create the new components folder inside the src directory
```
 mkdir src/components
```
Move the Button.js file into the new directory, and rename it so you can use TypeScript
```
 mv .storybook/stories/Button/Button.js src/components/Button.tsx
```

Move Button.stories.js to the .storybook/stories directory, and rename it to use TypeScript

 mv .storybook/stories/Button/Button.stories.js .storybook/stories/Button.stories.tsx

Remove the Button directory, as it is no longer needed
```
 rm -rf .storybook/stories/Button
```

Rename a few more files to use TypeScript

 mv .storybook/main.js .storybook/main.ts
 mv .storybook/preview.js .storybook/preview.ts
 mv .storybook/index.js .storybook/index.ts

Using TypeScript within components and Stories

Update the Button.tsx component to add a type for the props, and also add an additional flag for the disabled state

 // src/components/Button.tsx

 import React from "react";
 import { TouchableOpacity, Text, StyleSheet } from "react-native";

 export type MyButtonProps = {
   onPress?: () => void;
   text: string;
   disabled?: boolean;
 };

 export const MyButton: React.FC<MyButtonProps> = ({
   onPress,
   text,
   disabled
 }) => {
   return (
     <TouchableOpacity
       style={[styles.container, { opacity: disabled ? 0.3 : 1 }]}
       onPress={onPress}
       activeOpacity={0.8}
       disabled={disabled}
     >
       <Text style={styles.text}>
         {text}
       </Text>
     </TouchableOpacity>
   );
 };

 const styles = StyleSheet.create({
   container: {
     paddingHorizontal: 16,
     paddingVertical: 8,
     backgroundColor: "purple",
     borderRadius: 8,
   },
   text: { color: "white" },
 });

Update the Button.stories.tsx file to reference the Button component from the new location, and we’ll also use a few types from Storybook to get proper IntelliSense for the args on each story.

 import React from "react";
 import { View } from "react-native";
 import { MyButton, MyButtonProps } from "../../src/components/Button";
 import { Meta, StoryObj } from "@storybook/react-native";

 const meta: Meta<MyButtonProps> = {
   title: "Button",
   component: MyButton,
   argTypes: {
     onPress: {
       action: "onPress event",
     },
   },

   decorators: [
     (Story) => (
       <View style={{ flex: 1, justifyContent: "center", alignItems: "center" }}>
         <Story />
       </View>
     ),
   ],
 };

 export default meta;

 type Story = StoryObj<MyButtonProps>;

 export const Basic: Story = {
   storyName: "Basic",
   args: {
     disabled: false,
     text: "Tap me",
   },
 };

 export const Disabled: Story = {
   args: {
     disabled: true,
     text: "Disabled",
   },
 };

A few things to mention here:
- We are using the Meta type from Storybook to get better intelliSense for args and argTypes.
- We also added decorators to wrap and center stories within a View.
You can use the argTypes object inside meta to describe what control you want for each arg. If you want to learn more about available controls, checkout this link

Conclusions and closing words

I hope you find this post valuable! I would like to mention that the starter React Native template from Storybook was an amazing starting point. I just wanted to go the extra mile to set up everything with SDK 49, Expo Router, and TypeScript.

I would also like to thank:

oxeltra_beton for giving me the idea to combine Storybook, Expo Router v2, and SDK 49 and write about it.
Daniel Williams for all his contributions to the React Native and Storybook communities. I remember doing similar experiments with Expo and Storybook a few years ago, and I can't believe how much easier it was this time around. Thanks again, Daniel!

Please let me know if I’m missing something, or if I’m making a silly mistake in the process. I’m here to learn and improve.

Happy coding.

Using Storybook with Expo Router v2, SDK 49 & TypeScript

Comments (4)

More from this blog

Collecting payments with React Native & RevenueCat (Part 4): Building a Paywall screen

Collecting payments with React Native & RevenueCat (Part 3): Configuring Entitlements & Oferings in RevenueCat

Collecting payments with React Native & RevenueCat (Part 2): Configuring Subscriptions in the Stores

Collecting payments with React Native & RevenueCat (Part 1): Project & Apps setup

Best React Native UI Kits (February - 2024)

Introduction

Show me the code

What is Storybook, and how can it help you?

Setup options

Storybook web

Storybook native

Setting up an Expo project with Expo Router v2 and SDK 49

Adding TypeScript

Adding support for Path Aliases (Optional)

Adding Storybook to the project

Opting out from package version validations for Storybook dependencies

Using client environment variables to conditionally load Storybook UI

Updating metro config

Loading Storybook with `npm start`

Cleaning up

Using TypeScript within components and Stories

Conclusions and closing words

Command Palette

Comments (4)

More from this blog

Introduction

Show me the code

What is Storybook, and how can it help you?

Setup options

Storybook web

Storybook native

Setting up an Expo project with Expo Router v2 and SDK 49

Adding TypeScript

Adding support for Path Aliases (Optional)

Adding Storybook to the project

Opting out from package version validations for Storybook dependencies

Using client environment variables to conditionally load Storybook UI

Updating metro config

Loading Storybook with npm start

Cleaning up

Using TypeScript within components and Stories

Conclusions and closing words

Loading Storybook with `npm start`
